| Model | LRS-150W-5 | LRS-150W-12 | LRS-150W-15 | LRS-150-24 | LRS-150-36 | LRS-150-48 | |
| Output | DC Voltage | 5V | 12V | 15V | 24V | 36V | 48V |
| Rated Current | 22A | 12.5A | 10A | 6.5A | 4.3A | 3.3A | |
| Current Range | 0-22A | 0-12.5A | 0-10A | 0-6.5A | 0-4.3A | 0-3.3A | |
| Rated Power | 110W | 150W | 150W | 156W | 154.8W | 158.4W | |
| Ripple & Noise | 100mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 200mVp-p | 200mVp-p | |
| Voltage Adj. Range | 4.5-5.5V | 10.2-13.8V | 13.5-18V | 21.6-28.8V | 32.4-39.6V | 43.2-52.8V | |
| Voltage Tolerance | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| Line Regulation | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Load Regulation | ±1.0% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Setup, Rise Time | 500ms,30ms/230VAC 500ms,30ms/115VAC (At full load) | ||||||
| Hold Up Time | 16ms/230VAC 12ms/115VAC (At full load) | ||||||
| Input | Voltage Range | 85-264VAC | |||||
| Frequency Rage | 47-63Hz | ||||||
| Efficiency | 85.0% | 87.5% | 89.0% | 89.0% | 89.0% | 90.0% | |
| AC Current | 3A/115VAC 1.7A/230VAC | ||||||
| Inrush Current | Cold start: 60A/230VAC | ||||||
| Leakage Current | ＜ 0.75mA/240VAC | ||||||
| Protection | Overload | 110%-150% rated output power | |||||
| Hiccup mode: recovers automatically after the fault condition is removed | |||||||
| Over Voltage | 5.75-6.75V | 13.8-16.2V | 18.75-21.75V | 28.8-33.6V | 41.4-48.6V | 55.2-64.8V | |
| Hiccup mode: recovers automatically after the fault condition is removed | |||||||
| Safety | Standard | CE, ROHS, CCC | |||||
| Environment | Working Condition | -30～+70℃, 20～90% rated humidity, non-condensing | |||||
| Storage Condition | -40～+85℃, 10～95% rated humidity | ||||||
| Temp. Coefficient | ±0.03%/℃ (0～50℃) | ||||||
| Vibration Resistant | 10-500HZ 2G 10min/cycle, 60 minutes each for X, Y, and Z axes | ||||||
| Dimension | 159*97*30 mm(L*W*H) | ||||||
