| Model | LRS-50-3.3 | LRS-50-5 | LRS-50-12 | LRS-50-15 | LRS-50-24 | LRS-50-36 | LRS-50-48 | |
| Output | DC Voltage | 3.3V | 5V | 12V | 15V | 24V | 36V | 48V |
| Rated Current | 10A | 10A | 4.2A | 3.4A | 2.2A | 1.45A | 1.1A | |
| Current Range | 0-10A | 0-10A | 0-4.2A | 0-3.4A | 0-2.2A | 0-1.45A | 0-1.1A | |
| Rated Power | 33W | 50W | 50.4W | 51W | 52.8W | 52.2W | 52.8W | |
| Ripple & Noise | 80mVp-p | 80mVp-p | 120mVp-p | 120mVp-p | 150mVp-p | 200mVp-p | 200mVp-p | |
| Voltage Adj. Range | 2.97-3.6V | 4.5-5.5V | 10.2-13.8V | 13.5-18V | 21.6-28.8V | 32.4-39.6V | 43.2-52.8V | |
| Voltage Tolerance | ±3.0% | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| Line Regulation | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Load Regulation | ±2.0% | ±1.0% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Setup, Rise Time | 1000ms,30ms/230VAC 2000ms,30ms/115VAC (At full load) | |||||||
| Hold Up Time | 30ms/230VAC 12ms/115VAC (At full load) | |||||||
| Input | Voltage Range | 85-264VAC | ||||||
| Frequency Rage | 47-63Hz | |||||||
| Efficiency | 80% | 83% | 86% | 88% | 88% | 89% | 90% | |
| AC Current | 0.95A/115VAC 0.56A/230VAC | |||||||
| Inrush Current | Cold start: 45A/230VAC | |||||||
| Leakage Current | ＜ 0.75mA/240VAC | |||||||
| Protection | Overload | 110%-150% rated output power | ||||||
| Hiccup mode: recovers automatically after the fault condition is removed | ||||||||
| Over Voltage | 3.8-4.45V | 5.9-7.3V | 13.8-16.2V | 18.75-21.75V | 28.8-33.6V | 41.4-48.6V | 55.2-64.8V | |
| Hiccup mode: recovers automatically after the fault condition is removed | ||||||||
| Safety | Standard | CE, ROHS, CCC | ||||||
| Environment | Working Condition | -30～+70℃, 20～90% rated humidity, non-condensing | ||||||
| Storage Condition | -40～+85℃, 10～95% rated humidity | |||||||
| Temp. Coefficient | ±0.03%/℃ (0～50℃) | |||||||
| Vibration Resistant | 10-500HZ 2G 10min/cycle, 60 minutes each for X, Y, Z axes | |||||||
| Dimension | 99*82*30 mm(L*W*H) | |||||||
